Welded frame sized to the part or carton it carries
The fixture comes first: once we know the part, the shelf spacing, side guides and stops follow from it.
Industrial Transfer Cart / Warehouse Trolley
Custom Industrial Transfer Carts for Factory and Warehouse
Made-to-order warehouse trolleys and transfer carts for moving parts, cartons and work in progress. Low-platform utility trolleys, shelf carts, rack carts or a purpose-built fixture — typical builds run tube Ø20–50 mm with 1.2–3.0 mm wall, deck plate 0.8–3.0 mm and casters 75–200 mm. We build to your drawing, around the load, the route and the aisle width.
Get a Quote Within 24 Hours
Materials: steel, stainless steel or aluminum by project
Load: engineered to your target cargo and route
Wheels: PU, rubber, nylon or pneumatic with brake options
Finish: powder coating, plating, galvanizing or stainless
Product Overview
Built Around Load, Movement, Storage and Safety
Doing Metal can customize trolley structure based on your drawings, product photos, sample design, working environment, and quantity target. We review frame strength, caster layout, platform or shelf design, finish, and packing before quotation.
Buyer Problem and Custom Solution
Internal transfer carts usually fail where the fixture meets the frame: shelves that deflect under a full load, dividers that bend, or a cart that cannot be pushed through the narrowest door on the route. Buyers also need the same cart again in six months, which means the drawing has to be repeatable.
Doing Metal Solution
Send a drawing, a photo of the part or a sample cart. We review the load, the part geometry, the fixture layout, tube section, caster rating, finish and packing, then confirm what we would change for manufacturability before quoting. Drawings and jigs are kept on file so a repeat order matches the first one.
Shelf, rack, divider or fixture layout built to the part geometry
Dividers, padded zones and rack arms are welded or bolted depending on whether the cart will ever be reconfigured.
Caster rating and layout matched to route length and floor
Route length, floor joints and elevation changes decide wheel diameter and tread material.
Powder coat, galvanized or stainless finish
Wash-down, outdoor and food-handling routes change both material and finish, so we ask before quoting.
Workshop Photos
What We Actually Build, Photographed in Our Own Workshop
Every photo on this page was taken in our own workshop or at our customer site. No stock images, no renderings.
Transfer cart — the fixture is designed around the part it carries.
Built to drawing — shelf spacing and guides follow one specific part.
Same cart from the side — rack pitch and base clearances set by the part geometry.
Mesh-side platform trolley — welded mesh keeps loose cartons and totes on the deck.
Front view — removable push handle, mesh on all four sides, flat steel deck.
A batch in final inspection before packing — repeat builds hold the same geometry.
Bolt-on casters with welded corner gussets — casters can be swapped in the field.
Customization
Custom Options to Confirm Before Quotation
These options change material use, process route, tooling, assembly time, packing volume, and final cost.
Shelf, rack or fixture layout
Tube diameter and wall thickness
Dividers, stops, side guides or padded contact zones
Wheel diameter, tread and brake layout
Tow bar, coupling arm or AGV interface
Powder coat, galvanized or stainless finish
Engineering Choices
Key Details That Change Trolley Performance and Cost
Foreign material handling buyers often compare the same trolley by load class, wheel system, ergonomic design, towing method, surface finish, and packing. Confirming these details early helps avoid under-built carts and unnecessary cost.
Frame and Deck
Tube size, plate thickness, reinforcement ribs, weld layout, and deck surface should match the real load, cargo footprint, and impact during use.
Caster Layout
Two fixed plus two swivel wheels, four swivel wheels, brake casters, pneumatic tires, or larger PU wheels can be selected for different routes and floor conditions.
Push, Pull or Tow
Manual push handles, double handles, tow bars, coupling arms, forklift handling, or AGV interface requirements can be reviewed for custom projects.
Safety and Parking
Brake position, side rails, mesh guards, anti-slip decks, wheel locks, and load distribution help make the trolley safer during loading and parking.
Finish Durability
Powder coating, galvanizing, stainless steel, or custom color should be selected based on indoor/outdoor use, corrosion exposure, and brand requirements.
Export Packing
Assembled, semi-assembled, knock-down, carton, pallet, and spare wheel packing options affect freight volume, assembly time, and after-sales support.
Quality Checks
Inspection Points for This Trolley Type
Quality checks are adjusted according to the actual trolley type, structure, load, and application.
Fixture fit against the real part
Shelf deflection under full load
Weld inspection at load points
Caster rolling and brake holding test
Frame squareness and diagonal check
Finish and packing protection inspection
Angle and squareness checked against a template on every welded frame.
Joint-by-joint angle checks happen during assembly, not only at final inspection.
Same gauge, same angles — that is how unit 500 matches unit 1.
Specifications
Custom Trolley Specification Options
| Item | Options to Confirm |
|---|---|
| Load Capacity | Confirmed from the actual cargo, load distribution, route, floor and safety factor; the quotation should not rely on a generic load class alone |
| Sheet / Tube Thickness | Confirmed from material grade, load path, part geometry and downstream process. Current thickness limits are reviewed against the selected machine and drawing. |
| Material | Carbon steel, stainless steel, aluminum, steel mesh, or combined structure |
| Size | Standard or custom platform, shelf, cage, or drawer dimensions |
| Wheel Type | PU, rubber, nylon, pneumatic, fixed, swivel, brake caster, or heavy-duty caster |
| Structure | Flat platform, shelves, side rails, cage, drawers, foldable handle, knock-down packing |
| Finish | Powder coating, galvanizing, stainless finish, custom color, or other finish as required |
| MOQ / Sample | Standard MOQ is 50 units. For large-size or heavy-duty trolley projects, quantities from 10 units may be discussed. Sample and first-article arrangements are reviewed separately. |
| Lead Time | Quoted after drawing, material, quantity, finish, wheel sourcing and packing are confirmed |
| Packing | Fully assembled, semi-assembled, knock-down, carton, pallet and spare-part options |
| Branding | Logo, label, custom color, private-label packing, and distributor program support |
DFM and Inspection Review
Six Design Risks We Check Before the Trolley Enters Production
A drawing can look complete and still leave the most expensive problems unresolved. Attach your drawing or reference photos and identify these points before quotation.
Caster plate flatness, bolt pattern and wheel clearance
Load path from deck or shelves into the welded frame
Handle height, reach, turning space and operator access
Hole, slot and bend clearance around assembly interfaces
Finish build-up around threads, hinges and moving parts
Assembled or knock-down packing volume and protection
Applications
Where This Trolley Is Used
Production line transfer
Work in progress movement
Warehouse picking and replenishment
Parts and component handling
Assembly line supply
Cold store and food handling
Returnable packaging routes
Related Pages
Continue the Product and Process Review
These links help Google and buyers understand which page owns each topic, while giving your team the supporting process details.
Manufacturing Process
From Structure Review to Export Packing
The production route can include tube cutting, laser cutting, CNC bending, welding, surface treatment, wheel installation, final function checks, and export packaging. For OEM projects, drawings or samples help improve quotation accuracy.
RFQ Details Needed
- Product type, reference photo, or drawing.
- Overall size, platform size, shelf count, or cage dimensions.
- Target load capacity and cargo type.
- Wheel type, brake requirement, and floor condition.
- Material, finish, color, logo, packing, and order quantity.
FAQ
Common Questions Before Ordering Custom Trolleys
What makes a warehouse trolley suitable for picking?
The shelf height, usable shelf depth, handle position, caster layout and turning clearance should match the cartons, bins and route used by the operator. A picking cart is designed around the sequence of work, not only its outside dimensions.
Can you make a heavy duty warehouse trolley for narrow aisles?
Yes. Share the narrowest aisle, turning space, largest carton, target load and floor condition. We can then review the frame width, handle projection, shelf arrangement and caster layout before quotation.
What information is needed for an internal material handling cart?
Please send cargo dimensions and weight, route distance, floor joints or thresholds, working frequency, parking condition, shelf or bin layout, quantity and packing target.
Can you customize the size?
Yes. Overall size, platform size, shelf layout, cage size, handle height, and wheel configuration can be customized based on your use case.
Can I send a photo instead of a drawing?
Yes. Photos, samples, sketches, and use requirements can start the review. Drawings are recommended for accurate quotation and production.
Which wheel should I choose?
Wheel choice depends on load, floor type, noise requirement, movement distance, brake needs, and whether the trolley is pushed, pulled, or parked on slopes.
Can the trolley be foldable?
Foldable handles, foldable cages, removable shelves, and knock-down packing can be discussed when storage space or freight volume is important.
Do you support OEM branding?
Custom color, logo plate, label, carton artwork, and distributor packing can be reviewed for OEM and private-label trolley programs.
Can it work with towing equipment?
For heavy loads or long routes, please confirm tow bar, coupling arm, forklift, tugger cart, or AGV interface requirements during the RFQ stage.
What is the MOQ?
Our standard MOQ is 50 units for most custom trolley programs. For large-size or heavy-duty projects, quantities from 10 units may be discussed after reviewing the structure, material, casters, finish and packing. Samples and first articles are handled separately.
Can you quote from a PDF, DWG, DXF or STEP file?
Yes. Those formats are accepted for review, and reference photos or samples are useful when the drawing does not show the working environment.
How is lead time confirmed?
Lead time is confirmed after the drawing revision, material, quantity, finish, wheel model and packing method are agreed. We avoid giving a generic date that does not fit the project.
Can you provide supplier approval documents?
Tell us which documents your purchasing team needs. Material, inspection, packing and project records can be discussed, while certifications are published only after internal verification.
How will the trolley be packed?
We can review assembled, semi-assembled or knock-down packing, including cartons, pallets, hardware bags, labels and finish protection according to the shipping plan.
Can I request a sample or first article?
Yes. Sample or first-article review can be discussed according to the drawing maturity, project quantity, tooling and approval process.
Request a Quote for This Trolley
Send your trolley type, load capacity, size, wheel requirement, quantity, and drawings or reference photos. Our team will review the structure and reply within 24 hours on business days.
